We are a leading manufacturer of Roots Blower in Taiwan since 1990, we've been devoting ourselves to manufacturing Submersible type Roots Blower (GWB) , Re-circulated & Cooling Vertical type Roots Blower (GTB) , Suction Milk Pump (VTB) and Belt type Roots Blowers for over 30 years.

We have our own patents for above products in Taiwan and received TUV CE mark approval, ISO 9001, SGS / UKAS certificates. . . etc. We are the only one manufacturer in Taiwan to manufacture Submersible type roots blower, also is the only one manufacturer in the world to manufacture Re-circulated & Cooling Vertical type roots blower. Our unique design and modern products even occupy nearly 70% in Taiwan market. We have also exported our products to countries like America, UK, Australia, Czech, Switzerland, Bulgaria, Vietnam, U.K., Ukraina, Bangladesh, Sri Lanka, Vietnam, Malaysia, Singapore, etc, and we are continuously exploring opportunities elsewhere.

Re-circulated and Cooling Vertical-type Roots Blower
Major Specifications of Type GTB
Feature
Low Noise
High Efficiency
Small Vibration & Long Durability
Vertical Style For Saving Space
Protective Device For Reversing Rotation
Self Adjustment of Air Flow
(optional accessory)
Two stage Inlet silencer and totally closed re-circulated chamber for cooling the bearing more efficiency
Adoption of Full Close Outdoor Motor
(for blower to be installed in outdoor)
Exemption from Fixation
Re-circulated and Cooling Vertical-type Roots Blower
Bore Size : 1.5" to 8" (40~150A)
Air Capacity: 0.97 ~ 42.3 (m^3/min)
Maxi Pressure : 6000mmAq
(0.6 kgf/cm^2) (58.8kPa)
Noise : 50~95 db
Motor Power:0.5~75Hp (0.375~22.5Kw)

Quite-type Roots Blower
Major Specifications of Type KTB
Feature
Low Noise And Mini Size

Vertical Style For Saving Space

Small Vibration & Long Durability

Protective Device For Reversing Rotation

Self Adjustment of Air Flow
(optional accessory)



Quite-type Roots Blower
Bore Size : 1.25" to 1.5 " (32~40A)
Air Capacity: 0.41 ~ 0.84 (m^3/min) 410~840(liter/ min)
Maxi Pressure : 6000mmAq
(0.6 kgf/cm^2)(58.8kPa)
Noise : 45~49 db
Motor Power:0.5~2Hp(0.375~1.5Kw)

Tradictional Belt type Roots Blower
Major Specifications of Type TS/KS(2-lobes) & ARS/KRS (3-Lobes)
Feature
Great Flow

Long Durability

Cover well range size blower

Self Adjustment of Air Flow
(optional accessory)







Tradictional Belt type Roots Blower
Bore Size : 0.75" to 12 " (22~300A)
Air Capacity: 0.2~191.3 (m^3/min)
0.2K~191.3K (liter/min)
Maxi Pressure : 8000mmAq
(0.8 kgf/cm^2)(78.4kPa)
Motor Power:0.5~150Hp(0.375~112.5Kw)


Submersible type Roots Blower
Major Specifications of Type GWB
Feature
Silence

No need to add soundproofing devices

Great Endurance









Submersible type Roots Blower
Bore Size : 1.5" to 5 " (40~125A)
Air Capacity: 1.0~13.7 (m^3/min)
1.0K~13.7K (liter/min)
Maxi Pressure : 6000mmAq
(0.6 kgf/cm^2)(58.8kPa)
Motor Power:1~20Hp(0.75~15Kw)


Vacuum type Roots Blower
Major Specifications of Type VRS
Feature
Negative Pressure

Great Suction Flow











Vacuum type Roots Blower
Bore Size : 0.75" to 12 " (22~300A)
Air Capacity: 0.2~191.3 (m^3/min)
0.2K~191.3K (liter/min)
Maxi Pressure : - 5000mmAq
(-0.5 kgf/cm^2)(-49kPa)
Motor Power:0.5~150Hp(0.75~112.5Kw)


Water-Cooled type Roots Blower
Major Specifications of Type WRS
Feature
Water-Cooling

Suitable To Higher Pressure











Water-Cool type Roots Blower
Bore Size : 1.5" to 12 " (40~300A)
Air Capacity: 0.24~94.7 (m^3/min)
0.24K~94.7K (liter/min)
Maxi Pressure :10000mmAq
(1.0 kgf/cm^2)(98kPa)
Motor Power:0.5~150Hp(0.75~112.5Kw)
