沉水式_性能表
| 60HZ PERFORMANCE CHART OF GWB SERIES | ||||||||||||||||
| Pressure | 1000mmaq | 2000mmaq | 3000mmaq | 4000mmaq | 5000mmaq | 6000mmaq | Noise | Weight | ||||||||
| Model | Bore | Motor | CMM | KW | CMM | KW | CMM | KW | CMM | KW | CMM | KW | CMM | KW | DB | KG |
| GWB4075 | 1½B | 1Hp | 1.4 | 0.65 | 1.2 | 0.7 | 1.0 | 0.75 | 46 | 154 | ||||||
| GWB4015 | 1½B | 2Hp | 2.1 | 0.9 | 1.8 | 1.1 | 1.5 | 1.3 | 1.1 | 1.5 | 47 | 154 | ||||
| GWB5015 | 2B | 2Hp | 2.9 | 1.1 | 2.6 | 1.3 | 2.4 | 1.5 | 48 | 160 | ||||||
| GWB5022 | 2B | 3Hp | 2.9 | 1.1 | 2.6 | 1.3 | 2.4 | 1.5 | 2.2 | 1.8 | 2.0 | 2.0 | 50 | 164 | ||
| GWB5037 | 2B | 5Hp | 2.9 | 1.1 | 2.6 | 1.3 | 2.4 | 1.5 | 2.2 | 1.8 | 2.0 | 2.0 | 1.8 | 2.3 | 52 | 169 |
| GWB6522 | 2½B | 3Hp | 4.1 | 1.7 | 3.9 | 1.9 | 3.6 | 2.2 | 52 | 189 | ||||||
| GWB6537 | 2½B | 5Hp | 4.1 | 1.7 | 3.9 | 1.9 | 3.6 | 2.2 | 3.3 | 2.5 | 3.1 | 2.8 | 2.8 | 3.2 | 54 | 190 |
| GWB65A55 | 2½B | 7.5Hp | 5.4 | 2.0 | 5.1 | 2.2 | 4.7 | 2.5 | 4.4 | 2.9 | 4.1 | 3.5 | 3.8 | 4.0 | 59 | 233 |
| GWB8037 | 3B | 5Hp | 6.7 | 2.9 | 6.4 | 3.2 | 6.0 | 3.7 | 56 | 248 | ||||||
| GWB8055 | 3B | 7.5Hp | 6.7 | 2.9 | 6.4 | 3.2 | 6.0 | 3.7 | 5.7 | 4.3 | 5.3 | 5.0 | 59 | 267 | ||
| GWB8075 | 3B | 10Hp | 6.7 | 2.9 | 6.4 | 3.2 | 6.0 | 3.7 | 5.7 | 4.3 | 5.3 | 5.0 | 5.0 | 5.8 | 62 | 278 |
| GWB10055 | 4B | 7.5Hp | 9.4 | 4.0 | 9.0 | 4.6 | 8.6 | 5.2 | 63 | 293 | ||||||
| GWB10075 | 4B | 10Hp | 9.4 | 4.0 | 9.0 | 4.6 | 8.6 | 5.2 | 8.2 | 6.1 | 7.8 | 7.1 | 65 | 305 | ||
| GWB10011 | 4B | 15Hp | 9.4 | 4.0 | 9.0 | 4.6 | 8.6 | 5.2 | 8.2 | 6.1 | 7.8 | 7.1 | 7.4 | 8.2 | 67 | 318 |
| GWB12575 | 5B | 10Hp | 11.5 | 5.0 | 11.0 | 6.0 | 10.5 | 7.0 | 66 | 373 | ||||||
| GWB12511 | 5B | 15Hp | 11.5 | 5.0 | 11.0 | 6.0 | 10.5 | 7.0 | 10.1 | 8.1 | 9.6 | 9.4 | 9.1 | 10.6 | 69 | 386 |
| GWB125A11 | 5B | 15Hp | 13.7 | 8.2 | 13.3 | 9.3 | 12.8 | 10.3 | 69 | 425 | ||||||
| GWB125A15 | 5B | 20Hp | 13.7 | 8.2 | 13.3 | 9.3 | 12.8 | 10.3 | 12.4 | 11.2 | 12 | 13.0 | 11.6 | 14.5 | 70 | 450 |
| 50HZ PERFORMANCE CHART OF GWB SERIES | ||||||||||||||||
| Pressure | 1000mmaq | 2000mmaq | 3000mmaq | 4000mmaq | 5000mmaq | 6000mmaq | Noise | Weight | ||||||||
| Model | Bore | Motor | CMM | KW | CMM | KW | CMM | KW | CMM | KW | CMM | KW | CMM | KW | DB | KG |
| GWB4075 | 1½B | 1Hp | 1.1 | 0.55 | 0.9 | 0.65 | 0.7 | 44 | 154 | |||||||
| GWB4015 | 1½B | 2Hp | 1.6 | 0.84 | 1.3 | 0.99 | 1.1 | 1.14 | 0.85 | 1.25 | 0.65 | 1.4 | 47 | 154 | ||
| GWB5015 | 2B | 2Hp | 2.4 | 1.2 | 2.2 | 1.3 | 2.0 | 1.4 | 46 | 160 | ||||||
| GWB5022 | 2B | 3Hp | 2.4 | 1.2 | 2.2 | 1.3 | 2.0 | 1.4 | 1.8 | 1.6 | 1.6 | 1.8 | 1.5 | 2.0 | 48 | 164 |
| GWB6522 | 2½B | 3Hp | 3.4 | 1.5 | 3.2 | 1.7 | 3.0 | 1.9 | 2.8 | 2.1 | 50 | 189 | ||||
| GWB6537 | 2½B | 5Hp | 3.4 | 1.5 | 3.2 | 1.7 | 3.0 | 1.9 | 2.8 | 2.1 | 2.6 | 2.4 | 2.3 | 2.7 | 53 | 194 |
| GWB8055 | 3B | 7.5Hp | 5.6 | 2.4 | 5.3 | 2.7 | 5.0 | 3.1 | 4.7 | 3.7 | 4.4 | 4.2 | 4.1 | 4.8 | 58 | 267 |
| GWB10055 | 4B | 7.5Hp | 7.8 | 3.4 | 7.5 | 3.9 | 7.1 | 4.4 | 6.8 | 5.1 | 61 | 293 | ||||
| GWB10075 | 4B | 10Hp | 7.8 | 3.4 | 7.5 | 3.9 | 7.1 | 4.4 | 6.8 | 5.1 | 6.5 | 6.0 | 6.1 | 6.8 | 64 | 305 |
| GWB12575 | 5B | 10Hp | 9.5 | 4.2 | 9.1 | 5.0 | 8.7 | 5.9 | 8.3 | 6.8 | 66 | 373 | ||||
| GWB12511 | 5B | 15Hp | 9.5 | 4.2 | 9.1 | 5.0 | 8.7 | 5.9 | 8.3 | 6.8 | 7.9 | 7.9 | 7.5 | 8.9 | 69 | 386 |
沉水式_性能曲線圖
60Hz 沉水式鼓風機性能曲線圖
50Hz 沉水式鼓風機性能曲線圖
