We are a leading manufacturer of Roots Blower in Taiwan since 1990, we devote ourselves to manufacture Submersible type Roots Blower (GWB) , Re-circulated & Cooling Vertical type Roots Blower (GTB) , Suction Milk Pump (VTB) and Belt type Roots Blowers for over 18 years.
We have our own patens for above products in Taiwan and received CE mark approval, ISO 9001, SGS / UKAS certificates. . . etc. We are the only one manufacturer in Taiwan to manufacture Submersible type roots blower, also is the only one manufacturer in the world to manufacture Re-circulated & Cooling Vertical type roots blower. Our unique design and modern products even occupy about 70% in Taiwan market.
Re-circulated and Cooling Vertical-type Roots Blower
Major Specifications of Type GTB |
Feature |
 |
 Bore Size : 1.5" to 6" (40~150A) |
Low Noise |
|
| Air Capacity: 0.49 ~ 19.8 (m^3/min)
0.49K ~ 19.8K (liter/min) |
High Efficiency |
|
| Maxi Pressure : 6000mmAq (0.6 kgf/cm^2) (58.8kPa) |
Small Vibration &Long Durability |
|
| Noise : 50~95 db |
Save Space |
|
| Motor Power:0.5~30Hp (0.375~22.5Kw) |
Reverse Rotation Protection Device |
|
| Self Adjustment of Air Flow (optional accessory) |
||
| Mandatory Cooling by using the cool air to re-circulate and cool the bearing |
||
| Adoption of Full Close Outdoor Motor (for blower to be installed in outdoor) |
||
| Exemption from Fixation |
Quite-type Roots Blower
Major Specifications of Type KTB |
Feature |
 |
| Bore Size : 1.25" to 1.5 " (32~40A) |
Low Noise |
|
| Air Capacity: 0.41 ~ 0.84 (m^3/min) 410~840(liter/ min) |
Save Space |
|
| Maxi Pressure : 6000mmAq (0.6 kgf/cm^2)(58.8kPa) |
Small Vibration &Long Durability |
|
| Noise : 45~49 db |
Reverse Rotation Protection Device |
|
| Motor Power:0.5~2Hp(0.375~1.5Kw) |
Self Adjustment of Air Flow (optional accessory) |
|
Tradictional Belt type Roots Blower
Major Specifications of Type TS/KS(2-lobes) & ARS/KRS (3-Lobes) |
Feature |
 |
| Bore Size : 0.75" to 12 " (22~300A) |
Higher pressure |
|
| Air Capacity: 0.2~191.3 (m^3/min) 0.2K~191.3K (liter/min) |
Bigger volume |
|
| Maxi Pressure : 8000mmAq (0.8 kgf/cm^2)(78.4kPa) |
Longer endurance |
|
| Motor Power:0.5~150Hp(0.375~112.5Kw) |
Easier maintenance |
|
| Self Adjustment of Air Flow (optional accessory) |
||
Submersible type Roots Blower
Major Specifications of Type GWB |
Feature |
 |
| Bore Size : 1.5" to 5 " (40~125A) |
Quiet |
|
| Air Capacity: 1.0~13.7 (m^3/min) 1.0K~13.7K (liter/min) |
No need to add soundproofing devices |
|
| Maxi Pressure : 6000mmAq (0.6 kgf/cm^2)(58.8kPa) |
Longer endurance |
|
| Motor Power:1~20Hp(0.75~15Kw) |
||
Vacuum type Roots Blower
Major Specifications of Type VRS |
Feature |
 |
| Bore Size : 0.75" to 12 " (22~300A) |
Negative Pressure |
|
| Air Capacity: 0.2~191.3 (m^3/min) 0.2K~191.3K (liter/min) |
Bigger volume |
|
| Maxi Pressure : -5000mmAq (-0.5 kgf/cm^2)(-49kPa) |
||
| Motor Power:0.5~150Hp(0.75~112.5Kw) |
||
Water-Cooled type Roots Blower
Major Specifications of Type WRS |
Feature |
 |
| Bore Size : 1.5" to 12 " (40~300A) |
Water-Cooling |
|
| Air Capacity: 0.24~94.7 (m^3/min) 0.24K~94.7K (liter/min) |
High Pressure |
|
| Maxi Pressure :10000mmAq (1.0 kgf/cm^2)(98kPa) |
||
| Motor Power:0.5~150Hp(0.75~112.5Kw) |
||
Helical Rotor type Roots Blower
Feature |
 |
|
| Wide range for air volume、pressure and vacuum |
Lower energy consumption |
|
| Stable air flow and less Pressure variation |
Lower noise |
|
| Clean air not with oil moist |
Longer bearing life |
|
| Construction simple and easy maintenance |
||
| Bearings are all lubricated by oil moist |
||
